Key Features:
- Battery Compatibility: Designed for testing 48V, 24Ah LiFePO4 batteries, ensuring reliable and efficient performance evaluation.
- Charger Capacity: Utilizes a 24A charger to support fast and controlled charging operations.
- Discharge Mechanism: Integrated resistive load discharger enables precise and consistent discharge cycles under various conditions.
- Environmental Testing: Compatible with environmental chambers for testing batteries across a wide range of temperatures and humidity levels.
- Control & Monitoring:Operated through a dedicated PC application, enabling real-time control, monitoring, and data visualization.
- Voltage Range: Supports battery testing within a voltage range of 2V to 55V.
- Current Range:Handles charging and discharging operations from 0A to 24A, with adjustable rates.
- System Integration:Comprises both battery charger and resistive load units for seamless charge-discharge cycling.
- Application Areas:Ideal for performance, reliability, and lifecycle testing under simulated field conditions.
Battery Charger-discharger
- Voltage Range:2V to 55V
- Current Range:0A to 24A
- Charging Rate:Adjustable, up to 1C
- Load Type:Resistive load
- Control Interface:PC via USB
- Data Logging: Battery voltage, current, SOC, SOH, capacity
- Protections:
- Overtemperature
- Overcurrent
- Short circuit
- Short circuit
- Emergency stop
- Connectivity: External sensor input, USB
- Power Supply: 230V, 50Hz
Specifications:
Environmental Chamber
Environmental chambers are specialized enclosures designed to simulate and control various environmental conditions such as temperature, humidity, pressure, and sometimes light, vibration, or gases. These chambers are used extensively in industries such as electronics, automotive, aerospace, pharmaceuticals, and materials testing for research, development, and quality control purposes.
- Volume:50 litres (approx.)
- Temperature Range:-20°C to +70°C
- Humidity Range:20% to 90% RH
- Microprocessor-based
- PID temperature and humidity control
- Programmable settings
- ±1°C for temperature
- ±5% RH for humidity
- Inner: Corrosion-resistant stainless steel
- Outer: Powder-coated steel
- High-efficiency insulation
- Overtemperature / over humidity protection
- Electrical overload
- Emergency stop
- Visual + audible alarms
- Data Logging & Connectivity:USB, internal logging
- Power Supply:-230V, 50Hz
Specifications:
Control System:
Uniformity:
Construction:
Viewing Window:Tempered glass for observing test items
Safety Features:
